MM IoT SDK Hardware Bringup

mm-iot-sdk porting guide + hardware debugging: project structure, PA→scan→iperf tiers, SPI/SDIO HAL, and real-silicon bug patterns.

This skill covers two distinct but overlapping needs:

1. Starting a new port — how to structure the project, which components to implement and in which order, what hardware you need, and how to use the tiered example applications (porting_assistant → scan → iperf) to prove correctness at each stage.
2. Debugging a failing port on real hardware — the specific recurring bug species that only manifest on silicon, and the GDB-driven methodology for finding them quickly.

Read the whole skill before diving in. The porting structure sections tell you what to build; the debugging sections tell you why it doesn't work yet and how to find out for certain.

---

0. Before you start: do you actually need a custom port?

Morse Micro ships ready-made platform ports for Zephyr, ESP32, and CMSIS. If your host platform is one of these (or can target one of these ecosystems), use the existing port rather than writing a new one from scratch — see the MCU Platform Ports section of the mm-iot-sdk documentation.

For bare-metal or FreeRTOS-on-STM32 targets, Morse Micro already ships full reference shims for four STM32 families. Before writing new shim code, check whether your MCU is close enough to reuse one directly:

MCU family	mm-iot-sdk platform name
STM32H753xx	mm-ekh08-h753
STM32U575xx	mm-ekh08-u575
STM32U585xx	mm-mm6108-ekh05 / mm-mm8108-ekh05
STM32WB55xx	mm-ekh08-wb55

If none of the above fit, proceed with a custom port. The rest of this skill is that process.

---

1. Hardware requirements

Verify these before writing a single line of port code.

Transport bus

Choose one of SPI or SDIO — the SDK does not support sharing the bus with other peripherals and you implement only one HAL.

SDIO is generally more straightforward to bring up than SPI (Morse Micro's own finding): the SDIO protocol is more complex, but SPI host controller behavior varies widely across MCU vendors, making SPI shims harder to get right first time.

GPIO pins

Pin	Direction	Edge / Level	Notes
BUSY	Transceiver → Host	Rising edge	Prevents host from sleeping. Configure as input with rising-edge interrupt.
WAKE	Host → Transceiver	Output	Prevents transceiver sleeping. Hold HIGH permanently until power-optimisation phase.
RESET_N	Host → Transceiver	Active LOW	LOW resets transceiver (cold boot).
SPI_IRQ	Transceiver → Host	Falling edge	SPI only. Data-ready signal. Configure as input with falling-edge interrupt.
CSS	Host → Transceiver	Output	SPI only. Software chip-select for clock training sequence.

Critical: Even when WAKE is held permanently HIGH, you must call mmwlan_set_sleep_mode(MMWLAN_SLEEP_DISABLE) after booting the transceiver. Omitting this call will cause the driver to fail to boot, even though the WAKE line is correct.

Memory minimums

Resource	Minimum	Notes
Flash	2 MB	Enough for a debug build with firmware + BCF embedded as C arrays.
SRAM	256 KB	For morselib runtime + FreeRTOS + LwIP buffers + mmpktmem packet memory.

These are starting-point figures for bring-up. Final product sizing depends on your application; see Appendix A.5 of APPNOTE-45 for detailed flash and RAM breakdowns.

Recommended peripherals

• PKA (public key accelerator): accelerates ECC for WPA3/SAE association and reduces RAM usage during crypto operations.
• Hardware RNG: required by mbedTLS.

---

2. Recommended project structure

Do not place your project inside the mm-iot-sdk directory — it makes version upgrades and SDK patching fragile and blurs the boundary between your code and Morse Micro's code.

Instead:

text

YOUR_REPOSITORY/
  third_party/
    mm-iot-sdk-<version>/       <- version-controlled copy of the SDK
  your_application/
    Makefile
    include/
    src/
    targets/
      your_port/
        mm_shims/               <- most of your porting work lives here
        bsp/                    <- MCU-specific clock, peripheral, linker config
        platform.mk

• Use the MMIOT_ROOT environment variable everywhere your build system references SDK components. This lets you move or upgrade the SDK without touching every path.
• Keep mm_shims/ (the morselib HAL implementations) and bsp/ (MCU board bring-up) separate. The shims are portable across boards of the same MCU family; the BSP is not.
• The porting-stubs companion repository (see Appendix A.7 of APPNOTE-45) provides a starting skeleton to copy rather than building the stub from scratch.

---

3. The porting process: tiered validation

The port is complete when it passes all four tiers. Work through them in order — later tiers are impossible to diagnose correctly while earlier ones are still broken.

text

Tier 1  porting_assistant  -> OSAL + GPIO + bus HAL + BCF/FW loading verified
Tier 2  scan               -> transceiver boots, UMAC can probe for HaLow APs
Tier 3  iperf              -> full data path, TCP/IP, throughput benchmarked
Tier 4  your application   -> application-specific performance targets met

3.1 Build integration first

Before implementing anything:

bash

make -C applications/porting_assistant \
     MMIOT_ROOT=./third_party/mm-iot-sdk-<version>/framework \
     TARGET=targets/your_port

Flash the stub and confirm you can get any serial output. If the board is silent, the debug-probe setup or the UART driver is wrong — fix that before going further (see §7.4 below).

To identify exactly which source files, include paths, and build defines an example uses:

bash

make -C mm-iot-sdk/examples/<example>/targets/<platform> VERBOSE=1

Parse the VERBOSE output rather than guessing at file lists.

3.2 porting_assistant in four stages

Each stage has a definitive expected serial output. Use the output, not code review, to confirm a stage is actually passing.

Stage A — compile and get any output:

Implement mmhal_log_write() first. Provide ASSERT(false) stubs for anything else that fails to link. Expected output: all tests [ FAIL ].

Stage B — OSAL passes:

Implement the functions in mmosal.h and mmhal_os.h. Key functions exercised by the PA:

PA test	Function(s)
Memory allocation	mmosal_malloc_()
Memory reallocation	mmosal_realloc_()
Passage of time	mmosal_get_time_ms()
Task creation/preemption	mmosal_task_create()

If you are using FreeRTOS, use the existing mmosal_shim_freertos.c from the SDK rather than writing your own OSAL shim. Confirm your FreeRTOS version matches the SDK's (v11.2). Not all OSAL functions are exercised by the PA, but all of them must be implemented.

Expected output at end of Stage B: OSAL rows [ PASS ], all others [ FAIL ].

Stage C — communications HAL passes:

Implement GPIO manipulation functions first. Test each one individually with a logic analyzer before touching the bus driver: assert/deassert RESET, WAKE, read BUSY, etc.

Then implement the bus HAL (SPI or SDIO — see §4 and §5 for specifics). The PA will run a bulk write/read and a raw throughput test.

Expected output at end of Stage C: all rows through Raw throughput test [ PASS ], firmware rows still [ FAIL ].

Stage D — BCF and firmware:

Implement mmhal_wlan_read_fw_file() and mmhal_wlan_read_bcf_file().

The simplest approach: convert .mbin files to C arrays and compile them in:

bash

xxd -i <file.mbin> | sed 's/unsigned char/const unsigned char/' > <file.c>

Alternatively use the linker-object approach with INCLUDE_BCF_FILE_IN_APPLICATION (see framework/mk/morsefirmware.mk). See mmhal_wlan_binaries.c for a reference implementation.

Expected output: all tests [ PASS ], with a raw throughput line like:

text

Raw TPUT (kbit/s): 24615

3.3 Benchmark baselines

Use these to sanity-check your SPI/SDIO implementation once the PA passes. A result significantly below these numbers means your bus HAL or DMA config needs attention before proceeding to scan/iperf.

porting_assistant raw throughput (kbit/s):

Platform	Time (ms)	Transactions	Bytes	Raw TPUT
mm-mm6108-ekh05 (SPI)	2501	2254	6,743,968	21,572
mm-mm8108-ekh05 (SPI)	2501	2564	7,671,488	24,538
mm-mm8108-ekh05 (SDIO)	2501	11,670	34,916,640	111,688

iperf end-to-end throughput (Mbps, EKH05 boards):

Transceiver	Protocol	UDP DL	UDP UL	TCP DL	TCP UL
MM6108	SPI	18.0	18.0	8.1	6.4
MM6108	SDIO	24.0	24.0	9.5	7.0
MM8108	SPI	19.0	19.9	9.8	7.8
MM8108	SDIO	30.0	24.9	10.5	8.5

3.4 scan

Needs a HaLow AP (e.g. HaLowLink1, EKH01). Compile the same way as porting_assistant, substituting applications/scan. Remove optional components (mmconfig, mbedtls, littlefs) if you hit build errors — they are not required for scan to work. Set COUNTRY_CODE to a region present in mmregdb.c's regulatory_db_domains[].

Successful output: probe responses with BSSID, RSSI, S1G operation fields printed.

3.5 iperf

Configure iperf/src/mm_app_loadconfig.c (country code, SSID, passphrase, security type) and iperf/src/iperf.c (server/client mode, duration, port). Needs iPerf v2.x on the AP.

Compare results against the table in §3.3. If you're significantly below reference values, see §7.7 (throughput troubleshooting) before treating the port as complete.

---

4. SPI HAL specifics

Reference shims live at: mm-iot-sdk/framework/src/platforms/*/mm_shims/mmhal_wlan.c

Parameter	Requirement
Role	Host is SPI master; transceiver is slave.
Mode	Mode 0 only: CPOL=0, CPHA=0.
Bit order	MSB first.
Frame size	8-bit.
Duplex	Half-duplex protocol over full-duplex pins (both MISO and MOSI must be wired).
Clock frequency	20 MHz is a safe starting point; some platforms reach 40 MHz. See transceiver datasheet for max.
Chip select	Software-controlled GPIO — do not use the SPI peripheral's hardware NSS.
Training sequence	Host must clock >74 pulses with CS deasserted before the first transaction.
DMA	Strongly recommended. Use DMA for transfers >=16 bytes (DMA_TRANSFER_MIN_LENGTH); polled below.
Buffer alignment	Bulk read/write buffers passed to mmhal_wlan_spi_read_buf/write_buf must be 32-bit aligned.
Transfer timeout	Block on completion (DMA interrupt or equivalent) with ~10 ms per-transfer timeout.
SPI_IRQ polarity	Falling edge. The transceiver asserts SPI_IRQ low to signal data is ready.

Without DMA, the host will stall the morselib worker thread and throughput will be well below the reference figures in §3.3.

SPI debug loopback trick: Wire MISO directly to MOSI on the bench, then call the read/write functions and verify the bytes echo back correctly. This confirms your SPI peripheral config and GPIO chip-select logic before connecting the transceiver.

---

5. SDIO HAL specifics

Reference shims live at: mm-iot-sdk/framework/src/platforms/*-sdio/mm_shims/mmhal_wlan.c

Parameter	Requirement
Role	Host is SDIO controller; transceiver is SDIO card.
Bus width	4-bit (enable ENABLE_SDIO_4BIT). 1-bit is supported as fallback only.
Init clock	400 kHz during card enumeration (SD_INIT_FREQ_HZ).
DMA	Internal DMA (IDMA, single-buffer mode) required. Buffers 32-bit aligned, length multiple of 4.
Write timeout	750 ms.
Read timeout	1000 ms.
IRQ delivery	In-band via DAT1 (SDMMC peripheral delivers SDIO_IT_SDIOIT). No separate IRQ GPIO needed.
BUSY GPIO	Still required as a separate GPIO even with SDIO — BUSY is not carried in-band.

The transceiver presents two SDIO functions: function 1 (control, 8-byte block size) and function 2 (data, 512-byte block size). Communication uses CMD52 (single-register) and CMD53 (block/byte multi-access).

---

6. morselib: prebuilt vs. source

You can either compile morselib from source with your application, or link against the prebuilt libmorse.a in mm-iot-sdk/framework/morselib/lib/.

The prebuilt is available for:

• arm-cortex-m33f
• arm-cortex-m4f
• arm-cortex-m7f

You must use the NewLib-Nano C library implementation when linking against the prebuilt. Your CPU architecture and toolchain flags must exactly match one of the above configurations. If they don't, compile from source.

---

7. Debugging real hardware — the core rule

Every failure is a real bug until proven otherwise.

When a test step fails, hangs, or a board comes up silent, resist the urge to treat it as flaky hardware, a timing fluke, or something to work around. Chase every failure to its actual root cause before moving on. "Just retry" or "add a delay" almost never finds the real bug; they hide it.

The one exception: if code has been proven correct by cross-referencing a reference platform or by other tests on the same signal passing, ask the user to double-check the physical connection before assuming a software bug (see §7.10 below).

---

7.1 Don't trust "should be compatible" — read the real vendor source

New platforms are often built against an MCU family that's "basically the same as" a family already in the tree (e.g. GD32F4xx vs STM32F4). That similarity is real but incomplete, and the gaps are exactly where bugs hide:

• If a vendored driver library isn't available yet and code is hand-written from general knowledge of a "compatible" family, treat every register name, bit position, and function signature as unverified until the real vendor library is dropped in and diffed against. Function signatures shift (extra parameter on a PLL-config call), and constants that look parallel across families can occupy different bit positions in the same register.
• When two constants look like a matched pair (a "config/request" constant and a "status/readback" constant), check their actual definitions. A common vendor pattern is to have a _config() constant and a _get()/status constant that are not interchangeable even though they represent "the same" thing conceptually.
• Cross-validate GPIO/interrupt configuration against a working sibling platform. If the sibling configures an edge as rising-only and the new platform uses both edges, that's a strong signal of a bug, not an intentional difference.

---

7.2 Boot and vector table placement

If the board appears to still be running factory firmware after a successful flash:

• Cortex-M cores fetch the initial stack pointer and reset vector from fixed physical addresses at cold reset, independent of VTOR. If the linker script places .vectors/.isr_vector somewhere other than that physical boot address (e.g. assuming a bootloader will jump there) and no bootloader exists, the CPU boots whatever was already at address 0 — indefinitely.
• verify after programming only checks the bytes it wrote, not whether they're reachable.
• Check SystemInit() (or equivalent): some vendor startup code unconditionally forces VTOR to a fixed address on every boot.
• A BOOTLOADER memory region in a linker script does not guarantee a bootloader is actually built and flashed — it may be a reserved placeholder. If so, the fix is placing .vectors directly in the boot region, not writing a bootloader.

---

7.3 Debugging a silent/hanging board with GDB

Don't re-read "correct-looking" init code hoping to spot a bug. Attach GDB and find out where execution actually is:

1. openocd -f <platform's openocd.cfg> in one terminal, arm-none-eabi-gdb <elf> in another, target extended-remote :3333.
2. monitor reset halt, load (if needed), continue. If it hangs, Ctrl-C then bt.
3. If the backtrace lands in a generic fault/error handler called from multiple sites (very common for SystemClock_Config()-style functions with several if (...) Error_Handler() checks), disassemble the calling function, find each call site address, and set breakpoints at each to identify which specific check failed. Don't assume the first failing check in source order is the one that fired.
4. Prefer this over speculative code changes. A five-minute GDB session that shows "this readback returned 8, code expected 2" is worth more than three guesses at a fix.

---

7.4 Silent serial output — check the probe first

Before chasing a UART driver bug:

• Confirm the debug-probe config isn't a leftover placeholder (e.g. J-Link config when the board ships with a CMSIS-DAP probe). Set an explicit target chip name if the config relies on auto-detection.
• If the probe is a separate dongle, its UART header may be an independent USB-to-serial bridge with no built-in connection to the target. "No serial output" can simply mean the probe's TX/RX header was never jumpered to the target MCU's UART pins.
• If flashing tooling auto-detects the platform via OpenOCD target name, make sure the new platform is registered in that lookup table — a missing entry looks like flash corruption but is really just a missing config registration.

---

7.5 Transceiver fails to boot (SPI_IRQ)

Symptom: mmwlan_boot() returns MMWLAN_ERROR.

Cause: SPI_IRQ not implemented correctly. The transceiver uses the SPI_IRQ line (falling edge) to signal that data is ready for the host to read. If the interrupt is not wired up and calling the registered handler, the transceiver cannot complete boot.

Fix: Verify SPI_IRQ is configured as a falling-edge input interrupt and that mmhal_wlan_register_spi_irq_handler() / mmhal_wlan_set_spi_irq_enabled() are correctly implemented. Check with a logic analyzer that the line actually toggles during boot.

---

7.6 Flash / config-store address bugs

Code that maps a flash address to "which erasable sector is this" often uses bare equality checks (address == sector_start) rather than range containment checks (start <= address < start + size). The equality form silently returns "not found" for any address that falls within a sector without being its first byte.

This manifests as a config-store or filesystem failure deep inside a generic storage library — a confusing "can't find valid partition" or assertion that looks like flash corruption but is actually a HAL bug one level below. When you see an address-to-sector/block lookup, verify it does a real range check and test it against both the first and last byte of a region.

---

7.7 Lower than expected throughput

Symptoms: Raw TPUT in porting_assistant significantly below §3.3 baselines, or iperf results far below the reference table.

Common causes and fixes:

1. No DMA, or DMA misconfigured. The reference shims use DMA for transfers >=16 bytes and fall back to polled for smaller transfers. Without DMA the morselib worker thread stalls. Check DMA is enabled and that the channel/stream config is correct.

2. DMA access width mismatch. If mmpktmem buffers were moved to a different SRAM region (e.g. from default SRAM to a larger DTCM), check that the DMA controller is configured for 32-bit access to the new region. The 8-bit config may have worked for the original SRAM type but silently degrades throughput on the new one — a known real bug on an existing port.

3. Code executing from XIP flash. If the linker places code in QSPI execute-in-place flash rather than internal SRAM, the QSPI bus becomes a bottleneck. Check whether the platform vendor provides an alternate linker definition to copy code to RAM at boot.

4. Interrupt handlers not returning quickly. Keep ISRs minimal; defer work to tasks via queues or semaphores.

5. Insufficient packet memory. Ensure mmpktmem allocation is sized correctly for your network stack buffer requirements (LwIP uses pbufs).

To diagnose: capture a logic-analyzer trace of the bus and look for large idle gaps or inconsistent clock behaviour.

---

7.8 GPIO/EXTI "looks parallel, isn't" configuration

Interrupt trigger-edge configuration is an easy place to introduce a doubling bug: configuring "both edges" when only one is semantically meaningful (e.g. BUSY where only the asserting edge should trigger) causes every toggle to fire the handler twice. This surfaces as a test that counts interrupt invocations getting exactly 2x the expected count — a strong signal to check the trigger type, not the counting logic.

For SPI_IRQ specifically: the edge is falling (transceiver asserts low). For BUSY: the edge is rising. Getting these reversed produces spurious or missing interrupts that are extremely hard to trace without a logic analyzer.

Whenever you write or review edge-trigger configuration, add a comment stating which specific edge matters and why, and verify the code matches the comment.

---

7.9 HostAP multiple-definition linker errors

Symptom: Multiple definition linker errors on HostAP symbols.

Cause: Your project already includes HostAP (e.g. for a 2.4 GHz interface) and morselib brings in its own modified version.

Fix: Name-mangle the Morse Micro HostAP and all references to it in morselib. See Appendix A.6 of APPNOTE-45 for the procedure.

---

7.10 Distinguish software bugs from wiring bugs

Make the call based on evidence, not a guess:

• If a companion chip's SPI/register communication has already passed other tests (clock, data, and chip-select demonstrably working), and only one specific signal fails, and that signal's software-side mapping is shared/chip-agnostic code already used identically by other working platforms, the software is unlikely to be the problem — say so and ask the user to physically check that specific connection.
• Don't reach for "probably miswired" as a first resort. Only do so after you've ruled out the software path via the reasoning above or via GDB/register inspection.

---

8. Document every finding immediately

Each confirmed hardware-only bug is expensive to rediscover. For every confirmed bug:

1. Fix it with a comment at the fix site explaining why the old code was wrong — include specific evidence (GDB register values, the failing address) so the reasoning is reconstructable later.
2. Add an entry to the platform's provenance/history doc describing symptom, root cause, and fix in enough detail for a future porter to pattern-match against it on a different platform.
3. Keep the platform's README "read this before using on real hardware" section current with a count and one-line summary of confirmed bugs, so a new user knows what's been shaken out.

---

9. Quick checklist for a fresh bring-up session

Work through these in order. Later categories only surface once earlier ones are fixed.

1. Pre-port: Zephyr/ESP32/CMSIS port or STM32 reference shim covers the target? Use it.
2. Hardware verified: >=2 MB flash, >=256 KB SRAM, SPI or SDIO wired, GPIO pins correct.
3. Project structure: mm-iot-sdk in third_party/, MMIOT_ROOT used, mm_shims/ and bsp/ separate.
4. Debug probe: config matches actual hardware (probe type, chip name, UART wiring to target).
5. Board boots new firmware: vector table lands at the real boot address; not still running factory firmware.
6. PA Stage B — OSAL passes: memory alloc, time, task preemption all [ PASS ].
7. PA Stage C — bus HAL passes: SPI/SDIO startup, chip ID, BUSY, bulk R/W, raw TPUT all [ PASS ]; raw TPUT within ~20% of reference baselines in §3.3.
8. PA Stage D — BCF/FW passes: all PA tests [ PASS ].
9. scan passes: transceiver boots, probe responses appear.
10. iperf passes: end-to-end data path verified, throughput benchmarked against §3.3 table.
11. Only after 1-10 are solid: debug application-level / protocol-level behaviour. Failures there are much harder to diagnose correctly while a lower-level bug still lurks underneath.

---

10. Component dependency reference

When assembling your build, use this dependency table to avoid missing includes:

Component	Depends on
morselib	HostAP
mmutils	morselib
mmpktmem	morselib, mmutils
mmconfig	morselib
mmregdb	morselib
mmipal	lwip, morselib, mmutils (IP_STACK=lwip required)
mmiperf	lwip, morselib, mmutils (IP_STACK=lwip required)
mmping	lwip, morselib, mmutils (IP_STACK required)
lwip	mbedTLS (only when altcp_tls_mbedtls.c is compiled)
mbedtls	lwip (via net_lwip.c, only when IP_STACK set), morselib
hostap	morselib (os_mmosal.c, morse_stubs.c); mbedTLS (crypto_mbedtls_mm.c)

mmconfig, mbedtls, and littlefs are optional for the scan and iperf examples and can be removed from the build without affecting their main functionality if they cause build issues.
