openclaw-pi-shell-acp

OpenClaw plugin that adds a pi-shell-acp provider — an ACP bridge to Claude Code, Codex, and Gemini CLI backends, using your own locally authenticated credentials.

Status: prerelease 0.0.x. Published package path for early adopters. The plugin is usable, but the current implementation is still a child-pi stub; the self-contained ACP transport lands in a later phase. ClawHub releases may remain hidden from normal install surfaces until review completes.

What it does

Adds a single new provider, pi-shell-acp, to your OpenClaw setup. Models appear in the picker as:

• pi-shell-acp/claude-sonnet-4-6
• pi-shell-acp/claude-opus-4-7
• pi-shell-acp/gpt-5.4
• pi-shell-acp/gpt-5.5
• pi-shell-acp/gemini-3.1-pro-preview

Each model routes through the ACP backend of your choice (Claude, Codex, or Gemini) using credentials you have already set up locally for those tools.

The curated list mirrors pi-shell-acp's own SUPPORTED_*_MODEL_IDS in the bridge runtime. Other model IDs in the same families may work through the plugin's generic fallback path but are not part of this prerelease's tested surface.

What it is not

• Not a credential reseller. Uses your own existing local auth.
• Not a Claude Code / Codex / Gemini emulator. Each backend keeps its own model, API, and tool semantics.
• Not an acpx fork. It is an alternative install path for users who want OpenClaw to talk to ACP backends through a different bridge.
• Not a subscription multiplexer. No shared auth, no proxy.

Requirements

• OpenClaw >=2026.5.12 <2026.6.0.
• Locally authenticated Claude Code / Codex / Gemini CLI (one or more), each through their own normal auth flow — inside whatever runtime OpenClaw is actually running in (host, Docker container, remote machine). See Docker boundary below.
• pi binary on PATH (this plugin spawns a child pi process per turn to handle ACP framing).
• @junghanacs/pi-shell-acp installed into that same pi runtime (see If you do not already use pi).

If you do not already use pi

This plugin is only the OpenClaw adapter. It does not bundle the pi runtime, pi-shell-acp, or backend credentials. Install these in the same runtime where OpenClaw runs — the host for native OpenClaw, or inside the OpenClaw container for Docker deployments.

# 1. Install the pi binary.
npm i -g @earendil-works/pi-coding-agent
pi --version

# 2. Install the pi-shell-acp bridge into pi.
pi install npm:@junghanacs/pi-shell-acp

# 3. Wire and smoke the bridge from a throwaway workspace.
mkdir -p ~/pi-shell-acp-smoke
cd ~/pi-shell-acp-smoke
"$(npm root -g)/@junghanacs/pi-shell-acp/run.sh" install .

# Pick the backend you actually installed and authenticated.
"$(npm root -g)/@junghanacs/pi-shell-acp/run.sh" smoke-claude .
# or: "$(npm root -g)/@junghanacs/pi-shell-acp/run.sh" smoke-codex .
# or: "$(npm root -g)/@junghanacs/pi-shell-acp/run.sh" smoke-gemini .

At least one backend must also be installed and authenticated in that same runtime: Claude Code, Codex, or Gemini CLI. pi-shell-acp ships the Claude/Codex ACP server packages it needs, but it never provides Claude/Codex/Gemini credentials or subscription access.

For Docker, run the commands above in the OpenClaw gateway container or bake them into the image that runs the gateway. Then apply the Docker auth / ~/.pi overlay policy below.

Docker boundary

If your OpenClaw runs inside Docker, the backend CLI (Claude Code / Codex / Gemini) must be authenticated inside the container that runs OpenClaw, because that is where this plugin spawns pi and where pi reads ~/.claude, ~/.codex, ~/.gemini.

There are two supported ways to satisfy this. The plugin does the same thing in both cases; the difference is operator policy. The same choice applies independently per backend (you can do in-container login for one and host passthrough for another).

This plugin does not copy, proxy, decrypt, or otherwise mediate any backend credential. It only spawns a child pi process and lets that process read whatever the official CLI would read. The choice above is about which filesystem the official CLI is reading from, not about pi-shell-acp's behavior.

Also required inside the container, but independent of the auth choice above: the pi binary itself, the pi-shell-acp package installed against that pi, and the backend ACP executables — codex-acp and gemini on PATH. The OpenClaw image is responsible for layering these in; this plugin assumes they are present at runtime.

Pi agent overlay (~/.pi)

There is one more Docker concern, separate from backend auth. The child pi process writes runtime state into ~/.pi/agent/ (backend config overlays, session JSONLs, cached resolver state). Two operator policies cover it:

The plugin does not write to ~/.pi itself. It only spawns pi, and pi (via pi-shell-acp running inside it) is what touches the overlay. If you skip both options, the child pi will still function, but each container restart starts from a blank overlay.

Child skill PATH and emacs socket

The child pi process inherits whatever environment OpenClaw exposes to it. Two host-side env elements affect whether the documented skill surface is usable from inside the container:

1. PATH — host pi-skills ship co-located CLI binaries at <pi-overlay>/claude-plugin/skills/<name>/<name> (e.g. gitcli, denotecli, lifetract, gog). Skill docs use bare-command invocation (e.g. gitcli day ... from day-query's SKILL.md), which requires these directories to be on the child's PATH. The container's default PATH does not include them.

2. PI_EMACS_AGENT_SOCKET — the emacs skill connects via emacsclient -s "$PI_EMACS_AGENT_SOCKET". In a Docker container the emacs socket bind-mount typically lands at /run/emacs/server; the short-name form (server) does not resolve, because emacs's short-name resolver looks at $XDG_RUNTIME_DIR/emacs/ instead. Set the full socket path, not the short name.

Recommended compose environment: for ACP-route bots that use these skills (adjust <home> to the OpenClaw user's home inside the container — /home/node for stock OpenClaw images, /home/junghan for the maintainer's deployment):

environment:
  - PATH=<home>/.pi/agent/claude-plugin/skills/bibcli:<home>/.pi/agent/claude-plugin/skills/denotecli:<home>/.pi/agent/claude-plugin/skills/dictcli:<home>/.pi/agent/claude-plugin/skills/gitcli:<home>/.pi/agent/claude-plugin/skills/gogcli:<home>/.pi/agent/claude-plugin/skills/lifetract:<home>/.pi/agent/claude-plugin/skills/semantic-memory:/usr/local/sbin:/usr/local/bin:/usr/sbin:/usr/bin:/sbin:/bin
  - PI_EMACS_AGENT_SOCKET=/run/emacs/server

On NixOS hosts that bind-mount the Nix store into the container, also prepend the live emacs path (e.g. /nix/store/<hash>-emacs-nox-30.2/bin) — the hash rotates on each nixos-rebuild, so this entry needs synchronized refresh with the volumes: mount.

Worked example: junghan0611/nixos-config@3477206 (Oracle bbot deployment).

Followup. The plugin itself should prepare this env on the ACP code path (skill PATH augmentation + emacs socket detection) so operators don't carry this contract by hand. Tracked at #21. Until that ships, the operator-side compose env above is the documented workaround.

Native (non-Docker) installs do not need any of this — the official CLIs are already authenticated, ~/.pi is already populated, the host's PATH already includes the skill bin dirs, and the emacs socket is on its conventional path on the host where OpenClaw runs.

A note on the two npm scopes in this monorepo

This plugin (@junghan0611/openclaw-pi-shell-acp) and the root bridge (@junghanacs/pi-shell-acp) intentionally live under different npm scopes. Both are published by the same npm account (junghanacs); the @junghan0611 scope is a free public npm org under that account. The split exists because the plugin also needs to register on ClawHub, where the publisher handle @junghanacs is currently bound to an unresolved RFC and the publisher handle must match the package scope; the root bridge has no equivalent constraint (pi has its own provider ecosystem). Routine maintenance follows one account, two scopes.

Install

From ClawHub (preferred when review is available)

openclaw plugins install clawhub:@junghan0611/openclaw-pi-shell-acp
openclaw gateway restart
openclaw plugins inspect pi-shell-acp --runtime --json

ClawHub is OpenClaw's native discovery surface. Immediately after a new publish, the release may still be under ClawHub review and hidden from normal install/download surfaces. If this command cannot find the package yet, use the npm path below or wait for review to complete.

From npm

openclaw plugins install npm:@junghan0611/openclaw-pi-shell-acp
openclaw gateway restart
openclaw plugins inspect pi-shell-acp --runtime --json

Use the explicit npm: prefix when you want to skip ClawHub lookup and force npm resolution.

From source (development / emergency fallback)

git clone https://github.com/junghan0611/pi-shell-acp.git
cd pi-shell-acp/plugins/openclaw
openclaw plugins install "$(pwd)" --dangerously-force-unsafe-install
openclaw gateway restart

The --dangerously-force-unsafe-install flag is required only for untrusted local source installs because this prerelease spawns a child process. Do not use this flag for arbitrary third-party plugins. Prefer ClawHub or npm for normal installs.

After install:

openclaw plugins list --json
# Look for "pi-shell-acp" with status "loaded".

openclaw models list --provider pi-shell-acp --json
# Should show the five models above.

Recommended openclaw.json hygiene:

{
  "plugins": {
    "allow": ["pi-shell-acp"]
  }
}

Without an explicit plugins.allow, OpenClaw will print a startup warning about non-bundled plugins auto-loading.

Configuration

The plugin exposes five configuration keys (see openclaw.plugin.json for full schema). Two are wired in this prerelease; the rest are reserved for the next development phase.

Reserved keys are accepted by the schema for forward compatibility but do not change behavior in the prerelease. They land in Phase 1.4 when the stub is rewritten as a real ACP plugin.

Limitations (prerelease)

• ClawHub releases may be unavailable until review completes; use the explicit npm: install path as the fallback.
• The current implementation is a child-pi process stub, not the final embedded ACP transport. The child pi binary owns its own tool surface; OpenClaw-side tool routing for ACP backends is being tuned.
• Tested under Sonnet against the OpenClaw 2026.5.18 production baseline. The compatibility floor remains >=2026.5.12 <2026.6.0; other models work but are less exercised.
• Each turn emits a [pi-shell-acp DIAG] ... line to the gateway's stdout for diagnostic purposes. This is intentional during prerelease and goes away with the Phase 1.4 rewrite.

Boundary statement

This plugin connects OpenClaw to locally authenticated ACP backends through an explicit bridge. It does not patch OpenClaw core, does not bypass authentication, does not restore hidden transcripts, and does not resell access to any frontier model provider. If you do not have your own working install of Claude Code / Codex / Gemini CLI, this plugin will not give you one.

Issues

File issues at https://github.com/junghan0611/pi-shell-acp/issues. Mention [openclaw plugin] in the title.

License

MIT.
